Product Introduction
The wood crusher is a specialized equipment series for wood crushing, invented through years of research and design tailored to the industrial production needs of China. The crushing chamber employs a multi-stage crushing process and fine crushing principle device. It can chip branches and trunks with a diameter of 1 to 20 centimeters, and is also suitable for chipping fibrous stalk materials such as bamboo, cogongrass, corn stalks, and sorghum stalks.
It assembly consists of a main unit, a fan, an analyzer, a powder collector, a dust collector, and other components. The coarse crusher does not contain the analyzer, powder collector, dust collector. And the output size of coarse crusher is within 10cm. Fine crusher 1-2cm.
Key Features
The entire unit is driven by a single electric motor. It features a simple structure and a compact layout, resulting in low energy consumption, high efficiency, and high output. The machine operates stably with low noise. It is affordable, economical, and practical.
The equipment delivers high impact force and has a strong fine-crushing capability. By adopting a multi-stage crushing process combined with a dual-crushing principle (integrating blade cutting with high-speed airflow impact), it significantly enhances production efficiency.
Product Parameters
| Model | JP1500 |
| Rotor Diameter: | 800mm |
| Qty of Hammer: | 108pcs |
| Hammer Dimensions: | 230mm*60mm*8mm |
| Hammer Material: | M65 |
| Main Motor Speed: | 2000 r/m |
| Main Motor Power: | 75kw+75kw |
| Fan Power | 3kw |
| Discharge Auger Power | 3kw |
| Dust Collector Model | 1000 ( 36bags) |
| Basic Machine Dimensions: | 2500*2500*2800 |
| Capacity: | 5-6t/h |
| Feeding Conveyor Size: | 600*8000mm |
| Feeding Conveyor Power: | 3kw |
| Start Method: | Full-function control cabinet |
| Machine Color: | Multiple color for customization |
Performance
