Product Introduction
The heavy-duty single-shaft shredder, also known as a swing-arm single-shaft shredder, is an upgraded version of the standard single-shaft shredder. It is primarily used for processing large-sized materials such as home appliance shells, pipes, and tires, achieving high-efficiency shredding through a swing-arm feeding system and hydraulic drive.waste, and paper recycling.
Key Features
Heavy-Duty Shredding Power
Hydraulic swing-arm feeding + high-torque drive for fast shredding of large & bulky materials.
Stable, Safe, Low-Noise Operation
Siemens PLC control + water-cooled hardened-gear reducer + vibration damping, with overload protection for reliable running.
Customizable for Different Materials
Multiple cutter roller options (hard material / high-performance / film) + interchangeable screens (e.g., φ40 mm) for plastics, metals, wood, and more.
Product Parameters
| Model/Specification | JP2500 |
| Motor Power | 132kw*2 |
| Qty of Blades | 238 pcs |
| Blade Dimensions | φ 60mm*60mm*34mm |
| Shredding Chamber Size | 2500mm*2500mm |
| Inlet Size | 2500mm*2500mm |
| Basic Machine Dimensions | 6300mm*3300mm*3250mm |
| Output Particle Size | 95%≤100mm |
| Capacity | 30-50t/h |
